3DXMAX ASA 3D Printing Filament
3DXMAX® ASA (Acrylonitrile Styrene Acrylate) is a high-performance, UV-resistant polymer designed for technical applications requiring superior weatherability and a professional matte finish. It is the ideal upgrade from ABS for parts exposed to sunlight and harsh outdoor environments, commonly used in the automotive, marine, and RV industries.
Key Features
- UV and Weather Resistance: Exceptional stability against sunlight and radiation, making it perfect for long-term outdoor use.
- High Thermal Properties: Features a high glass transition temperature (Tg) of 105°C for heat-intensive applications.
- Industrial Aesthetics: Produces a low-gloss, matte surface finish that effectively masks layer lines.
- Durable Mechanical Strength: Sturdy and rugged composition provides reliable performance for functional engineering parts.
- Printability: Formulated to be easier to print than many other industrial-grade materials.
Specifications
| Property | Specification |
|---|---|
| Filament Diameters | 1.75mm and 2.85mm +/- 0.05mm |
| Extrusion Temperature | 235°C - 255°C |
| Bed Temperature | 90°C - 110°C (lower by 10-20°C after first layers) |
| Bed Surface | Magigoo or Polyimide Tape |
| Glass Transition (Tg) | 105°C |
| Drying Instructions | 80°C for 4 hours |
| Heated Chamber | Recommended to reduce warping |
For complex geometries, 3DXMAX ASA is compatible with water-soluble AquaTek X1 USM supports.
